Key Switch - long plunger

LT2 Short-travel Key Switches

Short travel and with extension plunger. High reliability contact and excellent tactility. This switch is perfect for Medical equipment, Industrial control, Automotive.

Features

• Long service life: 1,000,000 cycles

Specification

• Contact Rating: 100mA, 42VAC / DC
• Mechanical Life: 1,000,000 cycles
• Contact Resistance: 100mΩ max. (initial)
• Insulation Resistance: 1,000MΩ min.
• Dielectric Strength: 2,000VAC
• Operation Force: 3N ± 0.75N max.
• Dimension: 15 x 15mm, 19 x 19mm

Application

• Medical equipment
• Automotive
• Industrial control
