LED Display for advertising
Production Lead Time:
15 day(s)
Model No.:
BVO-20
Brand:
Xiwan
Colour:
full color
Port:
Shenzhen
Type of Payment:
T/T, L/C
Minimum Order Quantity:
5
Description
Contact Supplier
Description
- Energy saving: 40% of normal
- High definition: 400% of resolution
- High brightness: 150% of normal
- Much wide color gamut
- Pixel pitch (mm): P20
- Module resolution: 20 x 20
- Module size (mm): 256 x 256
- Pixel combination DIP: 1R1G1B1W
- Pixel density: 2500 pixels/㎡
- Driving way: static
- Cabinet size (mm): 1280 x 960
- Cabinet resolution: 64 x 48
- The number of modules: 20
- Cabinet type: fixed installation water proof iron box
- Cabinet weight (kg): 74
- Average power consumption (W/㎡): ≤108W/㎡
- The maximum power (W/㎡): ≤360W/㎡
- Brightness (Cd/㎡): ≥12000
- Gray scale: 16bit (4096 levels)
- Refresh rate: ≥800
- Brightness adjustment: 256 levels
- Frame frequency: 60Hz
- Input voltage: 110~220VAC
- Working temperature: -20℃~+ 50℃
- Work humidity: 10%-90%RH
- Best stadias: ≥16m
- The whole screen perspective: H: 120°; V: 60°
- IP rating: front: IP65; back: IP54
- MTBF (hrs): 1000
- Life span (hrs): 100000
