This STB75F LED Driver Series features UL-listed LED drivers built for wet-location UFO high bay lighting fixtures. Each LED driver from the series comes with an integrated emergency lighting system with driver and battery pack, supporting a wide range of lamp configurations. Designed for reliability and ease of use, it supports remote testing, smart control options and battery protection for long-term performance.

LED Driver — the STB75F Series

• Certifications: UL-listed for wet environments.
• Designed for UFO high bay applications.
• Infrared remote for quick testing.
• Optional Bluetooth module for app-based control.
• Compatible with 25–60W lamps with or without 0–10V dimming.
• 5-year warranty.

Temperature Management

• Operating temperature: 32°F to 140°F (0°C to >60°C).

Battery and Emergency Features

• Integrated emergency kit with driver and battery pack.
• Automatic initial functional self-check.
• Equipped with high-capacity, long-life LFP (LiFePO₄) or Li(NiCoMn)O₂ battery options.
• Rest mode for extended storage life.
• Built-in overcharge and over-discharge protection.
• Designed for a service life of up to 8 years under normal operating conditions.

Series Models

• STB75F-60WL-190-ST/BT
• STB75FH-60WL-400-ST/BT
• STB75F-40WL-190-ST/BT
• STB75FH-40WL-400-ST/BT
• STB75F-25WL-190-ST/BT
• STB75FH-25WL-400-ST/BT
