LED Stage Curtain Display Screen
Model No.:
MIF6D
Brand:
Joinmax
Colour:
RGB Full Color
Port:
Guangzhou
Type of Payment:
T/T, L/C
Description
Contact Supplier
Description
Showcased here is a LED display which is especially designed for indoor use. Each pixel of this LED display is form by 3 SMD LEDs. This high definition LED display can bestow you high quality graphic and image display.
- P6mm indoor LED display.
- Pixel pitch: 6mm.
- Pixel composition: SMD 3 in 1.
- Module resolution (L x W): 240 x 120 pixel
- Pixel density： 27778 pixel/sqm.
- Module size (L) x (W) x (D): 1280 x 640 x 100mm.
- Cabinet weight: 50kg.
- Brightness: >1800cd/sqm.
- Brightness control: 100 levels.
- Viewing angle horizontal: 120°/vertical 120°.
- Best viewing distance: 6-48m.
- Driving mode: 1/4 duty.
- Colors: 16.7 trillions.
- Grey scale: 14bit (16,384) levels.
- Cabinet power consumption: max: 1200W, average:720W.
- Refresh frequency: 1200Hz.
- Refresh frame frequency: 60Hz.
- Control mode: synchronization between PC and display.
- Power supply: AC200-240V 50-60 Hz.
- Protection grade: IP54.
- Operation temperature: -20 to + 60 ℃.
- Operation humidity: 10%- 90% RH.
