LED Surface Mounted Downlight

Production Lead Time:

20-35 day(s)

Shipping Method:

Air Freight, Sea Freight, Express

Model No.:

SDL01

Brand:

SIMONS

Customised:

Yes

Power:

10W, 12W, 15W, 16W, 18W, 20W, 22W, 25W, 28W, 30W, 35W, 40W, 45W, 50W, 55W, 60W, 65W, 70W, 75W, 80W

Lumens Efficiency:

80-90lm/w

Input Voltage:

220-240V

PF:

>0.9

Beam Angle:

15/24/36/60°

CCT:

Single Color (3000K-5000K), 3 CCT

CRI:

RA 80, 90

IP Rating:

IP20

Material:

Aluminum

Working Temperature:

-20~50℃

LED Chip:

COB

Light Body Colour:

White, Black

Installation:

Surface Mounted

Working Frequency:

50/60HZ

Lifetime:

30000Hrs

Application:

hotel, receiption, shop, office, mall, restaurant, bar etc

Certification:

SAA, C-Tick, CE, LM79, TM21, LCP, ISTMT, LM80

Origin:

Xiamen, China

Description

Contact Supplier

Features

1.Aluminimu body profile, concealed mounting screws and matt Black powder coat finish, optional White to order

2. Surface mounted architectural profile downlight

3. Durable aluminium body profile

4. High output COB LED chip, integral constant current trailing edge dimmable LED driver (excluding S9015/80GU10)

5. Optional to dimmable and non-dimmable

6. Dimmer Type: Trailing edge, 0-10V, DALI / DSI, Tuya Smart

7. Ideal for any residential or commercial interior spaces

8. Changeable to diff reflector and optional to 15˚, 24˚, 36˚, 60˚

Models

Model	Power	Diameter	Height
SM-SDL01-01-10	10W	74mm	147mm
SM-SDL01-01-12	12W	74mm	147mm
SM-SDL01-01-15	15W	74mm	147mm
SM-SDL01-02-16	16W	97mm	152mm
SM-SDL01-02-18	18W	97mm	152mm
SM-SDL01-02-20	20W	97mm	152mm
SM-SDL01-02-22	22W	97mm	152mm
SM-SDL01-02-25	25W	97mm	152mm
SM-SDL01-03-25	25W	115mm	135mm
SM-SDL01-03-28	28W	97mm	152mm
SM-SDL01-03-30	30W	97mm	152mm
SM-SDL01-04-35	35W	140mm	160mm
SM-SDL01-04-40	40W	140mm	160mm
SM-SDL01-05-45	45W	171mm	198mm
SM-SDL01-05-50	50W	171mm	198mm
SM-SDL01-05-55	55W	171mm	198mm
SM-SDL01-05-60	60W	171mm	198mm
SM-SDL01-06-65	65W	186mm	214mm
SM-SDL01-06-70	70W	186mm	214mm
SM-SDL01-06-75	75W	186mm	214mm
SM-SDL01-06-80	80W	186mm	214mm
