Linkable Dimming Surface Mounted Lights

Model No.:

KISS-C

Colour:

Silver(RAL9006), White(RAL9003), Black(RAL7021)

Size:

1,126 x 96 x 58mm

Port:

EXW Shenzhen

Type of Payment:

T/T

Minimum Order Quantity:

200

Customized:

Yes

Voltage(V):

AC200-240

Certification:

CE, EMC, LVD, RoHS

Wattage(W):

Warranty:

5 year

Body Material:

Aluminum

Description

Contact Supplier

New 1200mm linkable 4000k UGR<17 dali dimming surface mounted lights for office

Input Power: 50W
Power Factor: ≥0.9
Luminous Flux: 3200lm
Luminaire efficiency: 90lm/W
Color consistency SDCM: SDCM 3
Color Rendering: >80
Life Time: L80(B10)50,000H
UGR: ＜17
CCT: 3000k/4000k/6000k
Fixture Material: 6063AL
Housing Color: Silver/White
Protection Level: IP 20
Storage Temperature: -40℃~+80 ℃
Working Temperature: -20℃~+45 ℃
Features: Support DALI dimming, 1-10V dimming, and support wireless control system, such as CASAMBI and HCL function which can be realized with the DALI-DT8.
KISS-C adopts a magnetic installation structure. After the installation of the backing plate, the light-emitting lamp body can be directly attached and fixed to the backing plated after the safety cables is installed, the installation and maintenance is very simple, fast and efficient.
