Metal Waterproof Connector

Production Lead Time:

14 day(s)

Application:

Power and signal transition

Model No.:

KVG403

Brand:

Kolexam

Colour:

White grey

Size:

33mm x 90mm (Dia. x Length)

Port:

Hong Kong

Type of Payment:

Minimum Order Quantity:

100 piece(s)

Package:

Yes

Customised:

Yes

Type:

Circular connector

Gender:

One set (both plug and receptacle)

Description

Contact Supplier

Material: metal.
Waterproof metal push-pull 5P connector.
Housings are made by high grade plastic material.
5 pin (3 x 3.0mm pin+2 x 1.0mm pin).
Termination: crimping.
Rating voltage/current: 690V, 3 x 30A+2 x 7.5A
For wire section: ~3 x 6.0mm^2+2 x 0.75mm^2
IP protection: IP67
Coupling system: Push-pull.
Shielding: can be shielded with shielding cable gland.
Main features for KVG series.
Easy lock and protected against unlock by push-pull coupling.
High current and high voltage.
Shielded with the shielding cable gland in the back shell.
Durable metallic construction.
Long working life.
Note: the crimping type contacts will be supplied separately from the connector housing/body.
