New Arrival iPad Pencil ID730 Stylus Pen Digitizer with Magnetic Charging
Production Lead Time:
15 day(s)
Shipping Method:
Courier Express
Brand:
OEM
Customised:
Yes
Pen Type:
Active Capacitive Pen for iPad
Size:
Pen D=8.81mm L=166.7mm, Tip D=1.0mm
Weight:
12.49g
Model No.:
ID730
Charging Time:
2 hours
Battery:
125mAh
Charging Mode:
Magnetic Charging
Continue Working:
9 hours
Stand by:
12 months
Description
Contact Supplier
Description
iPad Pencil ID730 Stylus Pen Digitizer with Magnetic Charging,
- Only special for iPad some models.
- Adsorption charging
- High position accuracy
- Slant bold
- Level 100 system power display
- Commercial temperature range
- Replaceable tip technology
- General Spec
Parameter | Specifications | Unit | Note | |
Physical property | Pen Size(L/Φ) | 166.7±1.00 | mm | |
Pen Size(Φ) | 8.81±1.00 | mm | ||
Tip Size(Φ) | Φ1.0±0.3 | mm | ||
Color | White, optional | - | ||
Material | Plastics | |||
Weight | 12.49 | g | ||
Electrical property 电气特性 | Technology | Active-Capacitance | - | |
Hovering Height | ≤1 | mm | ||
Contact Accuracy | ≤±0.5 ≤±1 | mm | ||
Moving Latency | ≤25 | ms | ||
Down Latency<Active> | ≤35 | ms | ||
Programmable Switches | 1 | |||
Charging time | 2 | Hour | ||
Battery | 125 | mAh | ||
Working Hours | 9 | Hour | ||
Standby | 12 | month | ||
- Software Spec
1. Status: working mode, standby mode, sleep mode (enter after 5 minutes without any operation,
1) Working mode: The blue light is on, the pen is working normally.
2) Standby mode: The blue light is on, the low power consumption mode is running, and the pen wakes up to enter the working mode.
3) Sleep mode: the light is off, the pen does not work, you can wake up by pressing the button to enter the working mode, and you can wake up from the charging mode.
2. Charging status:
1) When charging: Red light breathing.
2) When fully charged, the green light stays on for 30 seconds and then turns off.
3. Key state: long press to power on, long press to power off, short press to enter the shortcut key function.
4. The status of the lights (three lights will only light one at the same time):
Red light: breathing light when charging, flashing when low power.
Blue light: Work is always on.
Green light: turn off after 30 seconds of full charge
- In the non-working state, the pen tip should not be stressed for a long time.
