5017-Y is a one-component epoxy adhesive with low viscosity, no need to add curing agent when using, and short curing time at 80~100℃. It is excellent for adhesion, heat resistance, electrical characteristics and moisture resistance. It is suitable for sealing of electronic and electrical appliances and all kinds of metal. This product meets ROHS requirements.

• Appearance and Characteristic

2.Gel time：150℃×30～45 seconds

3.Curing condition：95℃×60 minutes  or 105℃×50 minutes

4.Thixotropy：45°×95℃×60min×10～30mm

5.After curing：

6.Operation notice：

·Please preheat the glue within 45℃ before sealing, i.e. 38℃～45℃ for the best effect.

·After preheating, it can be used directly without vacuum.

·Recommended dispensing air pressure should be controlled between 0.1～0.3Mpa.

7.Continuous operating temp ：-40～140℃

The above performance data are typically measured in a laboratory environment with a temperature of 25 %, humidity of 70%. Customers need to do experiments to confirm whether it is applicable or not, because of many practical uncertainties. If you have any problem, contract to our technical service department, we’ll do our best.
