Outdoor Advertising Display Screen Board
Share this page
Model No.:
MOF16T
Brand:
Joinmax
Size:
1,024 x 768 x 180mm
Port:
Guangzhou
Minimum Order Quantity:
20 square meter(s)
Description
Contact Supplier
Description
This LED display screen features a 4.4 trillions colors vividly display. This LED display flaunts weatherproof functions with IP65 standard compliance. With 100 levels of brightness control, this display screen allows you to manipulate for the optimal performance.
  • Technical specification for P16 mm outdoor LED display.
  • Pixel pitch: 16mm (P10mm, P12mm, P14mm, P20mm are available).
  • Pixel composition: DIP 1R 1G 1B.
  • Module resolution ( L) x (W): 64 x 48dot.
  • Module size (L)x(W) x (D): 1024 x 768 x 180mm.
  • Cabinet weight: 60kg.
  • Brightness: >8000cd/sqm.
  • Viewing angle: horizental120°/vertical 60°.
  • Best viewing distance: 16-130m.
  • Driving mode: static 55mA/Pixel.
  • Colors: 4.4 trillions.
  • Cabinet power consumption: Max:900W Average:300W.
  • Brightness control: 100 levels.
  • Refresh frame frequency: 60 HZ.
  • Refresh frequency: 600HZ.
  • Control mode: Synchronization between PC and Display.
  • Power supply: AC200-240V 50-60 HZ
  • Protection grade: IP65.
  • Operation temperature: -20 to +50 ℃.
  • Operation humidity: 10%- 90% RH.
