PCB Layout
Port:
Shenzhen
Type of Payment:
T/T, PayPal
Minimum Order Quantity:
5 piece(s)
Copper Thickness:
1-3oz
Min. Hole Size:
0.1mm
Package:
Yes
Customised:
Yes
Board Thickness:
0.4-2.4mm
Min. Line Spacing:
0.1mm
Min. Line Width:
0.1mm
Base Material:
fr-4
Description
Contact Supplier
Description
- Files needed: Schematic(DSN or powerlogic), netlist, package, structure chart(DXF), Components file, layout requirements etc.
- Layout and wiring judgement: according to the design standard, design instruction, customer's design requirements and related checklist.
- Layout check and confirm: provide layout file and structure file to customer for checking if the layout makes sense and confirm the stack-up program, impedance program, structure and package, also confirm the trace specification
- Layout file output: PCB original file, gerber file, pick and place file, framed stencil file and structure file etc.
