PCB Manufacturing
Production Lead Time:
14 day(s)
Board Thickness:
1mm
Package:
Yes
Customised:
Yes
Description
Contact Supplier
Description
- Layer: 1 to 12 layers
- Material: FR-4, CEM-1, CEM-3, Hight TG, FR4 halogen free, FR-1, FR-2,Aluminum etc.
- Max. finished thickness: 0.2 to 4.0mm (0.02 ~ 0.25″)
- Max. finished board side: 500 x 500mm (20 x 20”)
- Min. drilled hole size: 0.25mm (10mil)
- Min. line width: 0.10mm (4mil)
- Min. line spacing: 0.10mm (4mil)
- Surface finish/treatment: HALS/HALS lead free, chemical tin, chemical gold, immersion gold, plating gold
- Copper thickness: 0.5 to 3.0 oz
- Solder mask color: green/black/white/red/blue
- Inner packing: plastic bag
- Outer packing: standard carton packing
- Hole tolerance: PTH: ±0.076, NTPH: ±0.05
- Certificate: UL, ISO 9001, ISO 14001, RoHS,UL
- Profiling punching: routing, V-cut, beveling
- Providing OEM service to all sorts of printed circuit board assembly
