Power Film Resistor
Model No.:
TNP-20S(TO220)
Port:
Incheon, Korea
Description
Contact Supplier
Description
This power film resistor is a surface-mounted and high-power resistor. It has a large resistance range from 100mΩ to 51KΩ. It is suitable for high-frequency applications and high-speed pulse circuits. It can handle 30W (surface mount) and 35W (through hole) in a compact molded package.
- Molded housing.
- Through-hole or surface-mount techniques.
- Low 2.3C/W heat resistance.
- Non-inductive.
- Offers excellent heat dissipation.
