The SH5141 Artificial-Intelligence Glow Wire Tester is designed and manufactured in accordance with IEC60695-2-10, GB169.10-13 standards.

The standard-based glow wire tip simulates the thermal stress produced by glowing elements or overload resistors, assesses the sample’s fire hazard charateristic. The test is applicable to the materials in electronics product, household appliances, etc.

Technical Parameters

Power supply: 220V 50Hz

Display & Control: 7-Inch-Screen(touch) + PLC

Glow Wire Temperature: 500℃~1000℃ preset

Temperature Precision: ≤±10℃

Glow Wire Tip: Φ4mm Ni(77%) Cr(20%)

Application Force: 0.95N(±0.1N)

Penetration Depth: 7mm(±0.5mm)

Application Time: 0-300s preset

Timing Mode: Auto(AI)/Manual

Speed of Carriage: within 10-25mm/s (motor-driven)

1mm Ni-Cr Sheathed Thermocouples (K-Type, accuracy class±0.5)

Temperature Calibration Function (with temp. rising curve displayed)

Fume Hood Volume: ≥0.5m³

Fume Hood Inwall: matte-black color, illuminance≤20lx

Accessories: remote control(1 pcs)/ pine board(1 pcs)/ silk layer(1 sheet)/silver foil(1 pcs)
