Slight Series - Side-Bend - NS-234-0506FC
Part No.:
NS-234SX24VEW-09-0506FC (With White Trim)
Style:
Side-Bend (White)
Dimension:
W5*H6mm [W0.2*H0.24in.]
Max. Run Length&Max. Shipping Length:
5M [16.4ft.]&30M [98.4ft.]
Increment:
Free cutting to be any length
LED Type:
SMD 2835
LED Qty:
240LED/M [73LED/ft.]
Voltage:
DC24V
Power:
9W/M [2.74W/ft.]
CCT/Wavelength:
2700K±120K 3000K±150K 3500K±300K 4000K±300K 5000K±400K 6000K±500K
Brightness@4000K&CRI90:
270lm/M [82lm/ft.]
Light Efficiency@4000K&CRI90:
30lm/W
Beam Angle:
120°
IP&IK Rating:
IP54 [Damp]
Description
Contact Supplier
Description
Features
-
-
1. Super flexible bending performance with ultra-slim in 3x6mm.
2. Plane profile supports flush mounting in the groove.
3. Uniform, dot-free, smooth and comfortable luminary up to 5M [16.4ft.] run length.
4. Field processing in free-cutting to be any length.
5. IP54 for indoor usage.
6. Dimmable available with PWM signal.
7. Compared with traditional fragile glass and harden/yellowing easily PVC sheathing material, silicon extrusion technology is an advanced process, with high-efficiency production capacity and environmentally-friendly characteristics. Additionally, with high grade appearance, soft bend flexibility, strong impact resistant and high weather resistance.
8. 50,000h long lifespan, 5 years warranty, for indoor usage.
9. CE & UL approval.
2. Plane profile supports flush mounting in the groove.
3. Uniform, dot-free, smooth and comfortable luminary up to 5M [16.4ft.] run length.
4. Field processing in free-cutting to be any length.
5. IP54 for indoor usage.
6. Dimmable available with PWM signal.
7. Compared with traditional fragile glass and harden/yellowing easily PVC sheathing material, silicon extrusion technology is an advanced process, with high-efficiency production capacity and environmentally-friendly characteristics. Additionally, with high grade appearance, soft bend flexibility, strong impact resistant and high weather resistance.
8. 50,000h long lifespan, 5 years warranty, for indoor usage.
9. CE & UL approval.
Details
-
-
Application
1. Ideal for furniture, cabinet, and display lighting in residential and commercial.
