Smart LED High Bay Light With Sensor
US $25.55 - US $28.41
US $26.90 - US $29.90
Production Lead Time:
20-25 day(s)
Shipping Method:
EXW
Brand:
TUBU
Is Dimmable:
Yes
Light Source:
LED
Description
Contact Supplier
Description
Tubu smart adjustable LED high bay light is designed to withstand harsh conditions, with IP65 and IK08 protection ratings, dustproof, waterproof, and impact-resistant. This high bay light operates seamlessly in temperatures ranging from -40°C to 50°C and has a lifespan of up to 50,000 hours, ensuring long-lasting performance and reliability.
Safety is the top priority in life, this smart adjustable LED high bay light with sensor is equipped with power protection functions including short circuit protection (SCP), over-voltage protection (OVP), and over-temperature protection (OTP). For added control and customization, dimming control options include 0-10V and PWM with an auxiliary power supply of 200MA at 12V. In addition, This high bay light offers an easy choice between single-lamp microwave sensors or group microwave constant illuminance controllers for efficient energy management.
Features:
- CCT Adjustable:4000K/5000K/5700K
- Wattage: 200W(dimming to 150W/100W)
- Lighting efficiency: 150LM/W(R80)/170LM/W (R80)/190LM/W(R70)
- Beam angle: 90°(Channel version: one Angle can cover more than 90% of the market)
- Protection grade: IP65 IK08
- Operating environment: -40~50℃,life span 50000H
- Power protection: power supply short circuit protected (SCP)/overvoltage protection(OVP)/over temperature protection(OTP).
- Dimming control: 0-10V/PWM, auxiliary power supply 200MA 12V.
- Controller selecting: single lamp microwave sensors/group microwave constant illuminance controllers are available in two standard configurations.
- Installation(suspending /wall mounted) Meet different customers’ demands.
- Quick Start instant 100% luminous flux
- 5 Year Warranty on complete fixture. (LEDs, Driver, & Housing)
- Body: Aluminium alloy, Stainless steel screws
Tech Specs
| Product Code | TBF12-200W |
| Power | 200W (adjustable 150W/100W) |
| Input Voltage | 100-277VAC (50/60HZ) |
| Input Current | 0.91A/220VAC |
| PF | 0-95V@220VAC |
| Dimming Option | 3 in dimming (PWM, 0-10V, resistor), Power dial or internal microwave controller |
| Dimming DC 12V driver | 12VDC±10%, Max current 200mA（Dimming ：External control and built-in microwave control can only be used，Only use in 12V） |
| CCT | 4000K/5000K/5700K |
| Ra>80Luminous Flux | 30000Lm±5%/34000Lm±5% |
| Ra>80 Efficiency | 150Lm/w±5% / 170Lm/w±5% |
| Ra>70 Luminous Flux | 38000Lm±5% |
| Ra>70 Efficiency | 190Lm/W±5% |
| LED Brand | SMD 3030 or SMD2835 |
| Working temperature and humidity | -40～50℃，20～95%RHnon-condensing |
| Storage temperature and humidity | -40～85℃，10～95%RH non-condensing |
| Life Span | 50000Hours |
| IP/IK Class | IP65 / IK08 |
| Surge lighting stroke | 6KV / 10KV |
| Certificate | Accord with ETL, CB, CE, PSE, SAA, ROHS2.0 |
| Material Color | Housing：die-casting aluminium/ Housing color：Black( RAL9005) Optics/ lens：PC |
| Product Size (mm) | ∅300*102mm |
| Packing Size (mm) | 360*145*340mm |
| Quantity/carton | 1PCS |
| Gross weight (kg) ±0.3 | 4.2 |
| Installation mode | Suspending/wall mounted(reference the instruction) |
