Sony 0.7" OLED Monocular Micro Display Module
Production Lead Time:
30 day(s)
Model No.:
R6
Brand:
ENMESI
Colour:
black
Size:
18.5mm x 20.3mm
Port:
Shenzhen
Type of Payment:
T/T, PayPal
Minimum Order Quantity:
50 piece(s)
Package:
Yes
Customised:
Yes
Description
Contact Supplier
Description
High Resolution OLED Monocular Micro Display Module For VR/AR Glasses
Product details
Applications
Product details
- Product model: R6
- Screen size :0.7"
- Resolution: 1920 & 1080
- Material: OLED
- FOV: 45°
- Eyerelief :19.5mm
- Eyebox: 8mm
- Distortion :1.42%
- MTF :0.15@ 30lp/mm
- Size :18.5mm x 20.3mm
- Weigh :14g
- Ultra high contrast.
- Wide color gamnt.
- Fast response speed.
- Thin and light in weigh.
- Thin thickness.
- Power saving (ps) function.
- Scan direction selection,up or down and right or left.
- Orbit supported.
- Wide range of use temperatures.
- Uniform picture quality.
- Image stability.
- The micro display module is a 1.8 cm (0.71inxh) diagonal, 1920(RGB) × 1080 dots active matrix color OLED (Organic Light Emitting Display) panel module based on single crystal silicon transistors. The module integrates panel driver and logic driver, and achieves smaller size, light in weight and high resolution.
Applications
- The micro-display module is mainly designed for the application of video glasses (eye-wearing, goggles,helmet-type observation system), game helmets, electronic viewfinder (EVF) devices and other products.
- Industrial Medical video display: Human and computer Imaging engineering research, dental clinic use,medical X-ray image, geological marine exploration and use, Scientific institutions of higher learning use.
- Military use: Military video (sight), multifunctional individual helmet system (individual Combat Command System), Individual night vision system, life detection video device, infrared night vision instrument, Infrared Thermal Imager, security monitoring and other devices (high-definition panchromatic remote observer, can be connected with a variety of monitoring or thermal camera systems).
