Stainless CNC Punching Machine
Model No.:
K120
Description
Contact Supplier
Description
Hardware:
- Feeding system: Roller continuous feeding mechanism
- Slotting system: Progressive Cutting Mechanism of White Steel Planer
- Bending system: Biaxial linkage arc bending system
- Motor: 2 servo motors and 2 stepper motors
- Equipment weight: 280kg
- Dimensions of the host: L1500mm × W800mm × H1300mm
- Dimensions of feeding station: L500mm × W500mm × H1100mm
- Material category: stainless steel, Galvanized sheet, Flat aluminum
- Height of material: 20mm-120mm
- Material thickness: Stainless steel (0.3mm-1.0mm), Galvanized sheet (0.4mm-1.2mm), Flat aluminum (0.6mm-1.5mm)
- Supported formats: PLT DXF NC
- Feeding accuracy: ± 0.1mm
- Arc radius: > 10mm
- Motion control: Zhongweixing four-axis motion control card / Lok Chong four-axis motion control card
- Software system: AutoDrive automatic bending system / CBS4 automatic bending system
- Input voltage: 220V 50Hz 3Kw
- Air pressure: 0.6-0.8 MPa
