Stud Type Circuit Breakers
Production Lead Time:
14 day(s)
Model No.:
E5
Brand:
Gloso
Colour:
Gray, Gold, Silver
Description
Contact Supplier
Description
Stud Type Circuit Breakers
Safety Approval:
- Product Name: Single Pole Thermal Type Breakers
- Description: Applications: Battery chargers, trucks, buses, RVs, trolling motors, etc
- Specification: Rating: 5-50A, 14Vdc; 28Vdc
- Interrupt Rating: Main Circuit Protection: 1.5kA @ 12Vdc
- Branch Circuit Protection: 2.5kA @ 12Vdc
- Operating Temperature Rating: -400F (-40C) to 185F (85C)
- Storage Temperature Rating: -40F (-40C) to 260F (125C)
- Materials: Black UL-Rated thermoplastic body (thermostat for Type II body & buttons). Cover is grey thermoplastic or steel-Type l gold, Type ll silver
- Marking: Custom marking available. Consult factory for options
- Termination: #10-32 thread and quick-connect options available
- Torque Rating: 24 in-lbs (2.7 Nm) max
- Mounting Torque Rating: Plastic cover - 15 in-lbs (1.7N Nm); Metal cover - 30 in-lbs (3.4 Nm)
Safety Approval:
- Compliances: SAE J553; SAE J1171 (ignition protected)
- Ingress Protection Rating: IP66 On plastic cover version only (except for terminals)
