Sugar Cube Miniature PCB Relay 10A
Production Lead Time:
7 day(s)
Model No.:
T73
Brand:
SHUNYU
Colour:
Blue, Black
Size:
19x15.5x15.5mm
Port:
Guangzhou, Shenzhen
Type of Payment:
T/T, L/C
Minimum Order Quantity:
1,000 piece(s)
Package:
Yes
Customised:
Yes
Contact Load:
Low Power
Protect Feature:
Epoxy
Usage:
General Purpose
Size:
Subminiature
Description
Contact Supplier
Description
- 产品型号Product Model
- JQX-3F/T73
- 触点形式 Contact Form
- 1Z,1H
- 接触电阻Contact Resistance
- ≤100mΩ(1A 6VDC)
- 触点材料Contact Material
- AgCdO AgSnO2
- 触点负载Contact Rating
- 7A 250VAC/30VDC
- 10A 250VAC/30VDC
- 绝缘电阻Insulation Resistance
- ≥100mΩ
- 介质耐压Dielectric Strength
- BCC≥1500VAC1min
- BOC≥750VAC 1min
- 引出端方式Termination
- PCB
- 额定线圈功率Rated Coil Power
- 360mW(48DC0.51W)
