TX Fanless Series (Multi-LAN) Barebone Industrial Computer
Production Lead Time:
7 day(s)
Model No.:
TX320
Brand:
OEM
Colour:
Black
Size:
187×115×52 mm
Port:
Shenzhen
Type of Payment:
T/T
Minimum Order Quantity:
5
Monitor Type:
None
Display aspect ratio:
None
Screen Size (Inch):
1
Package:
Yes
Customised:
Yes
Products Status:
Stock
Integrated Graphics Card:
Yes
Memory Capacity:
8 Gigabyte (GB)
Hard Disk Capacity:
8 Gigabyte (GB)
Processor Brand:
Intel
CPU Clock Speed:
1.7 Gigahertz
Description
Contact Supplier
Description
- Size: 187×115×52 mm
- Package:Weight 2kg
- Power:15W
- On board CPU: Intel Celeron Processor 3215U Quad-Core 1.7GHz
- Memory
- - 1 x Memory Slot，to 8GB max
- Support to DDR3 1333/1600 MHz low voltage version
- Storage
- - supports mSATA SSD
- - Support SATA 3.0 6Gb/s
- On board VGA Intel HD Graphics
- LAN 4× Intel I211-AT 10/100/1000 Controller
- Audio Realtek ALC662 HD Audio
- Front-Panel
- Connectors
- 1 × Power LED
- 1 x HDMI
- 2 x USB 3.0
- 2 x USB 2.0
- 1 × Serial port
- Internal
- I/Internal
- I/O
- 1 x MINI PCIE（support MSATA SSD）
- 1 x MINI PCIE（Wifi/BT/3G/4G module）
- 1 x DDR3 DIMM Memory Slot
- 1 x SATA data interface
- 1 x SATA power interface
- 1 x jump (auto start up)
- 1 x GPIO（*optional）
- 1 x SIM（*optional）
- Back-Panel
- Connectors
- 1 x DC 12V Power
- 1 × Power LED
- 1 × HDD LED
- 4 x RJ-45 LAN port
- 1 x Audio -in
- 1 x Autio -out
- 2 x Antenna （*with Wifi module）
- Last update: 2016-3-31
- Operating
- System
- Without default operating system
- - Support Windows XP/Windows 7 / Windows 8 / Windows 10
