Temperature Sensor
Model No.:
Series AVG
Brand:
Dwyer
Description
Contact Supplier
Description
- The series AVG averaging temperature sensor can be used to measure the average temperature up stream of the cooling coils in an air handler
- The coiled sensor unwinds to a length of 12 or 24' to take an average temperature reading across a large space
- The housing has multiple knockouts to reduce the time to install conduit
- The series CC1 mounting brackets can be used to secure the capillary to the wall of the air handler without kinking
- The series AVG can be ordered with a choice of 11 output options that allow it to communicate to any standard building control system
- Specifications:
- Accuracy: platinum RTD: ±0.6% at 32°F (0°C), nickel RTD: ±0.5°F at 32°F (0°C), Balco RTD: ±0.1% at 32°F (0°C), thermistors: ±0.36°F from 32 to 158°F (0 to 70°C)
- Operating temperature: -32 to 240°F (-35.5 to 115.5°C)
- Capillary length: 12 or 24' depends on model
- Cable length: 8"
- Probe material: bendable copper capillary
- Mounting: flanged mounting ears
