Product Parameter | Fuselage color | white |
Body size (L × W × H) | φ94.8*177mm |
optical parameter | Physical resolution | 720P (1280X720) |
Temperature | 8000K（±10%） |
luminance | 170 Ansi LM |
Contrast | 2000 |
evenness | 75% |
Projected aspect ratio | 16:9 |
Projective ratio | 0.8:1 |
Trapezoidal alignment | Automatic ladder |
Language | multilingual |
Lamp life | More than 30,000 hours |
Lamp type | White LED module |
Focusing mode | Manual focusing |
Control mode | Button/Remote control |
Projection distance | 0.6 m -2.5 m |
Projected size | 25-110 inches |
system parameter | Same screen image |
|
System | Android 11 |
CPU | Allwinner H713 |
Quad-Core ARM Cortex-A53 |
GPU | Mali-G31 supports OpenGL ES3.2,Vulkan 1.1,and OpenCL2.0 |
RAM | 1GB |
ROM | 8GB |
WIFI | AIC8800DC -- Dual band 2.4G/5G WiFi6 + BT5.4 Module |
BT | BT 5.4 |
basic parameter | Video format | Full-format decoding including HEVC/VP9/AVS2/AVC 4K@30fps and MPEG1/MPEG2/AV1 1080p/60fps decoding and so on |
Music format | MP3/WMA/ACC |
Picture format | JPG,BMP,PNG,support image scaling |
Key control | Power button |
Remote control | Infrared remote control |
External loudspeaker | 1X3W |
BT speaker | support |
Optical machine power consumption | 30W |
Overall power consumption | 38W |
Operating voltage | 36 v 0.95 A / 12 v 0.7 A |
port | USB X1, HD In X1, DCX1 |
Pilot lamp | LED (power red, power green) |
Projection mode | Forward throw, back throw |
Standby power consumption | 0.3 W |
packing parameter | Packing details | Color box, remote control, power supply, manual |
