    Tubular Low Glare UGR<16 LED Tri-Proof Light
    Share this page
    US $22.70 - US $199.50
    US $23.89 - US $210.00
    Production Lead Time:
    20-25 day(s)
    Shipping Method:
    EXW
    Brand:
    TUBU
    Feature:
    UGR<16 low glare
    Material:
    Milky PC/PMMA Housing & 304/316 Stainless Steel End Caps
    Customised:
    Yes
    CCT:
    3000K/4000K/5000K/6000K
    Dimming Option:
    0-10V/Dali
    Efficiency:
    130Lm/W±5%
    Beam Angle:
    50° UGR<16/ 80° UGR<19
    Description
    Contact Supplier
    Description

    The TUBU low glare UGR<16 LED tri-proof light is an ideal choice for indoor lighting due to its low-glare design. Additionally, it has widespread applications in various settings including commercial, public, and industrial areas. These include offices, architecture, and schools.

    One of the standout features of our TUBU UGR<16 LED Tubular light is its IP69 Waterproof rating. This rating signifies the highest level of protection, specifically designed for applications where high-pressure water jets and high temperatures are used for wash-down purposes. The TUBU UGR<16 LED Tubular Lights are environmentally friendly, containing no mercury, UV, or IR components. By using these lights, you can reduce your energy consumption significantly, up to 80%.

    Features:
    • IP67 & IP69K&IK10
    • PC IK10
    • Against water pressure of 100 Bar(1450psi) and temperature of 80℃
    • System efficiency up to 130lm/W
    • High CRI> 80
    • UGR<16
    • Environmentally friendly, no mercury, No UV, No IR
    • Wide beam angle of 80°
    • Energy Efficiency Grade: A+
    • Quick Start instant 100% luminous flux
    • 5 Year Warranty on complete fixture. (LEDs, Driver, & Housing)
    • Certificate: CE, RoHS Certified
    • Mounting: Surface Mount or Suspended


    Tech Specs:
    Product CodeTBL92F-20W-UGR16TBL94F-40W-UGR16TBL95F-50W-UGR16TBL95F-60W-UGR16
    Power20W40W50W60W
    Input Voltage200-240VAC/100-277VAC (50/60HZ)
    Input Current0.09A@220VAC0.19A@220VAC0.23A@220VAC0.28A@220VAC
    Power Factor0.90@220VAC
    Dimming Option0-10V/Dali
    Color Temperature3000K/4000K/5000K/6000K
    CRI>80Luminous Flux2600Lm±5%5200Lm±5%6500Lm±5%7800Lm±5%
    Efficiency130Lm/W±5%
    LED BrandLumileds/Hongli
    Beam Angle80°
    Operation Temperature-20℃~+40℃
    Storage Temperature-20℃~+60℃
    Life SpanTa 40℃ L70>54000Hours
    IP ClassIP67 & IP69K
    IK ClassPMMA IK08 & PC IK10
    CertificateCE, RoHs, CB, IK10, IP69K, ENEC
    Lamp Body MaterialMilky PC/PMMA Housing & 304/316 Stainless Steel End Caps
    Product Size ( mm )75*55275*115275*145275*1452
    Packing Size ( mm )730*260*2601330*260*1801630*260*1801630*260*180
    Quantity / Carton9pcs6pcs6pcs6pcs
    Gross Weight ( kg ) ± 0.312152323
    InstallationSurface Mount & Suspenion Mount
