Features:

• Supply Voltage: 90-305Vac or 127-420Vdc, 380Vac for 2 hours
• Great Surge Immunity 10kV
• PWM Output Frequency >1kHz
• 100,000Hour Life @ Tc=75℃
• 5 Year Warranty @ Tc<=75℃
• 0-10V/PWM/DALI /Push (Switch) /DMX (RDM) Dimmable
• 2% Minimum Dimming Output
• Dim Off with 0.5W Standby
• 12V 300mA Auxiliary Power to Power Controllers and Fans (Optional)
• Input Over Voltage Protection (Optional)
• Class II Model Available
• UL Class P, ENEC/CB/CCC SELV Output
• Safety according to EN 61347-1, 61347-2-3, 61347-2-13, 62384

Technical Data:

• Input Voltage: 90～305Vac or 127V-420Vdc, 380Vac for 2 hours
• Input Frequency: 47～63Hz
• Power Factor: >0.9@60-100%load, refer to PF vs. Load curve
• THD: <15%@60-100%load, refer to THD vs. Load curve
• Input Current: 0.95Amax@120Vac & Full-Load, 0.48Amax@220Vac & Full-Load
• Inrush Current: 65A peak, 1.2ms duration, <0.25A2s@230Vac, Cold Start; 70A peak, 1.3ms duration, <0. 5A2s@277Vac, Cold Start
• Leakage Current: 1mA max @277Vac 60Hz, UL8750,0.75mAmax @220Vac 50Hz, IEC61347-1
• Input Under Voltage: Shut down and auto-restart
• Input Over Voltage: *Optional: Shutdown @320Vac
• Surge Protection: Line to line 6kV, line to ground 10kV, IEC 61000-4-5
• Voltage Accuracy: ±3%Vo
• Setup Time: 1.2s max.
• Overshoot: 10% Vo, max.
• Output Over Current: 120% Io, typ.
• Short Circuit: Auto recovery. The output recovers when short is removed.
• Over Temperature: Turn off the output when Tc≧105±10℃; Auto Recovery When Tc≦70±10℃
• Operating Temperature: -40℃～+70℃ ；10%RH～100%RH
• Storage Temperature: -40℃～+85℃； 5%RH～100%RH
• MTBF: ≥320,000 hours, 75℃ case  temperature (MIL-HDBK-217F)
• Lifetime; ≥100,000 hours, 75℃ case  temperature, refer to life vs. Tc curve
• Case Temperature: 90℃ max, marked in the Tc point of label
• Dimensions: 6.34x2.66x1.32 by inch (body),   7.40x2.66x1.32 by inch (endcaps included); 161.0x67.5x33.5 by mm (body), 188.0x67.5x33.5 by mm (endcaps included)
• Net Weight: 800g
• Packing: 25pcs, 21kg per carton, carton size: 490x370x230mm

Notes:  Unless specified, all the test results are measured in 25℃ room temperature.
