USLINSKY Dual Rated Aluminum Mechanical Lugs

Product Overview

UL486B Listed (CU9AL) and rated 600V/90°C, these mechanical lugs are manufactured from high-strength 6061-T6 aluminum alloy to deliver maximum strength and conductivity. Dual-rated for both copper and aluminum conductors, they feature electro-tin plating for low contact resistance and corrosion protection. Ideal for reliable electrical conductor splicing and termination.

Key Features & Benefits

- Made from high-strength 6061-T6 aluminum alloy for optimal strength and conductivity

- Dual-rated for copper and aluminum conductors, with electro-tin plating to minimize contact resistance and prevent corrosion

- Re-usable design, easy assembly with only a screwdriver or Allen wrench

- Rated 600V, 194°F (90°C), compliant with UL486B (CU9AL) standards

- Available in one-conductor/one-hole, two-conductor/one-hole, and slotted screw mounting configurations

Technical Specifications

- Models: LTA-2, LTA-1/0, LTA-2/0, LTA-3/0 (one-conductor/one-hole); LAU-2, LAU-1/0, LAU-2/0, LAU-3/0 (two-conductor/one-hole); LAUS-300, LAUS-750L (two-conductor/one-hole with slotted screws)

- Material: 6061-T6 Aluminum Alloy, electro-tin plated

- Rating: 600V, 90°C (194°F)

- Certification: UL486B Listed (CU9AL), CSA Certified

- Wire Range: 2-14 to 350-6 (model dependent)

- Mounting: One-hole/two-hole options, slotted screw variants available

Application

For secure termination and splicing of copper and aluminum conductors in residential, commercial, and industrial electrical systems.
