VC99 1000V 20A 6000 Counts TRMS NCV Digital Multimeter
Model No.:
VC99
Size:
185*93*35mm
Weight:
290g
Safety level:
CAT. III 600V
Max display:
6000 digits
Voltage:
AC 750V DC 1000V0V
Current:
AC DC 20A
Capacitance:
60mF
Resistance:
60MΩ
Frequency:
10MHz
Temperature:
1000℃， 1832℉
Description
Contact Supplier
Description
VC99 1000V 20A 6000 Counts TRMS NCV Digital Multimeter
Features:
1. New type holster, streamline design;
2. Large LCD makes the reading clearly;
3. Strong antimagnetic and anti-jamming performance;
4. Full function protection;
5. Unit symbol display, very easy to reading;
6. Relative value, frequency/duty cycle measuring, data hold.
Basic function | Range | Basic Accuracy |
DCV | 600mV/6V/60V/600V/1000V | ±(0.5%+5) |
ACV | 6V/60/600/750V | ±(0.8%+10) |
DCA | 600uA/6000uA/60mA/600mA/6A/20A | ±(1.0%+5) |
ACA | 600uA/6000uA/60mA/600mA/6A/20A | ±(1.5%+10) |
Resistance | 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ | ±(0.8%+2) |
Capacitance | 60nF/ 600nF/6uF/60uF/600uF/6mF/60mF | ±(2.5%+5) |
Frequency | 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz | ±(0.5%+4) |
Temperature | -40℃～1000℃ | ±(0.8%+4) |
-40℉～1832℉ | ±(1.0%+5) |
Special Function:
Safety level | CAT. III 600V |
Max. display | 6000 |
NCV | √ |
Backlight display | |
TRUE RMS | √ |
Diode test | √ |
hFE test | √ |
Continuity test | Approx. less than 30Ω |
Low battery indication | Approx less than 2.4V |
Duty cycle measuring | √ |
Data hold | MAX./MIN., HOLD |
Auto power off | Approx.15minutes |
Analog bar | √ |
Function protection | √ |
Input impendence | 10MΩ |
Sampling rate | 3times/s |
AC frequency response | 40-2kHz |
Operation way | Manual or auto range |
LCD size | 65x41mm |
Battery | 3V (1.5V AAA×2) |
Power consumption | Quiescent current approx. 2mA |
General Characteristic:
Color | Orange and Gray |
Weight | 290g（including battery） |
Meter size | 185×93×35mm |
Standard accessory | |
Packing | Gift box |
Standard packing per carton | 30pcs |
Carton size | 43.5*29.5*40.5CM |
Standard G.W per carton | 17kg |
