VHF and UHF Two-Way Radio
Model No.:
NA-589
Brand:
NAGOYA
Customised:
Yes
Description
Contact Supplier
Description
- The pictured VHF and UHF two-way radio comes with a camouflage colored appearance for a fashionable touch. It comes with a dual-band design and has a wide frequency range for fulfilling your needs. This two-way radio is compatible with the American military standard (MIL-STD-810C/D/E).
- Frequency range: 136-174MHz, 350-390MHz, 400-480MHz, 480-520MHz.
- Working mode: U&V, U&U, V&V, V&U.
- Dual frequency display (caller ID).
- Dual frequency standby in any band.
- Receiving and transmitting inter-band.
- DTMF signaling system.
- Digital FM radio.
- 50 groups CTCSS and 105 groups DCS.
- ANI code display.
- All calls, group calls and selective calls.
- Alarm (distant urgency alarm and alarm at local).
- Non-standard CTCSS (can be edited arbitrary between 60Hz and 259.9Hz).
- TOT.
- High/low power shift.
- CTCSS or DCS can be set respectively.
- Channel step (5K, 6.25K, 10K, 12.5K, 25K).
- VOX function.
- Battery save function.
- Wide and narrow band selectable (N:12.5kHz/W:25kHz).
- Busy channel lockout.
- Low voltage alarm with sound and light.
- Auto backlight.
- Auto/manual keyboard lock.
- Three display color selectable both in transmitting, receiving and standby.
- Frequency, channel order and channel name multi-display mode.
- Calling ring function.
- DTMF.
- PTT-ID function.
- Mute mode (CTCSS/DCS, CTCSS/DCS and optional signal, CTCSS/DCS plus optional signal).
- Offset frequency (can be set between 0 and 69.9875MHz in frequency mode).
- Operating menu directly through keypad.
- Frequency, channel and menu fast search function.
- Channel parameter can be saved in the frequency mode.
- 128 channels.
- Reverse frequency function.
- U/V receiving and transmitting inter-band can be connected with a repeater.
- Wired cloning function.
- PC programmable.
- Frequency range FM: 87-108MHz (receiving).
- VHF: 136-174.995MHz (receiving & transmitting).
- UHF0: 350-390.995MHz (receiving).
- UHF1: 400-479.995MHz (receiving & transmitting).
- UHF2: 480-520.955MHz (receiving).
- Working mode: same frequency simplex or double frequency simplex.
- Memory channels: 128.
- Antenna impedance: 50Ω.
- Voltage: 7.5V.
