Waterproof Toggle Switch
Share this page
Model No.:
T600
Brand:
TOOWEI
Package:
Yes
Customised:
Yes
Max. Voltage:
250VAC
Operating Temperature:
-25 c to +80 c
Max. Current:
20A
Mechanical Life:
50000 Cycles
Max. Working Pressure:
24N
Description
Contact Supplier
Description
DPDT T600 Series 10A/15A 12mm Waterproof toggle switch guard cover
  • Rating value :10A 250VAC 15A 125VAC
  • Mechanical life:≥50,000 times
  • Electrical life:≥20,000 times
  • Contact resistance :<50MΩ
  • Insulation resistance:≥100MΩ
  • Withstand Voltage:1000V 50/60Hz last for 1min
  • Ambient temperature :-25°c~+80°c
  • Vibration:10~55Hz 1.5mm Double Amplitude
  • Operating force:≤24N
  • Dimensions:Diameter:Φ12.0mm+0.2
  • Installation:Bushing mount
  • Waterproof grade:need with waterproof cap
