YO2086s-1GC(R2W)
Production Lead Time:
14 day(s)
产品型号:
YO2086s-1GC(R2W)
Brand:
Yoswit
Size:
L: 86mm x W: 86mm x H: 32mm
Port:
Hong Kong, Zhongshan, China
Type of Payment:
PayPal, Bank Transfer
Minimum Order Quantity:
1 piece
Operating Temperature:
-10°C to 40°C
Max. Current:
6A
防护等级:
IP20
Package:
Yes
Customised:
Yes
Max. Voltage:
AC100 - 240V
Description
Contact Supplier
Description
Yoswit Smart Double-Pole Switch
Model: YO2086s-1GC (R2W)
Product Name: Yoswit Smart Double-Pole Switch
Panel Type: 86-type
Revision: V7.0
Designed by: Yoswit in Hong Kong, China
Assembled in: Guangdong, China
Certifications: CE, FCC, RoHS
Product Summary
A smart double-pole switch for high-power household appliances. It lets water heaters, air conditioners, exhaust fans and other heavy loads be controlled smartly — with energy monitoring, scheduling, hub/gateway functionality for other Yoswit devices, Wi-Fi + Bluetooth connectivity, third-party smart-home compatibility, and OTA upgrades.
Key Features
- Built for high-power appliances: Market-positioned as supporting 20A high-load devices — water heaters, AC units, exhaust fans, etc.
- Energy consumption monitoring: Real-time electricity usage insights; track energy second by second for energy-hungry appliances to reduce waste and save cost.
- Built-in schedule / timer: Weekly, daily, hourly or even per-minute rules. Schedule is stored in the switch and keeps running even if the phone disconnects.
- Acts as a Yoswit hub: Works like a central controller; built-in Wi-Fi connects other Yoswit products so all devices can be managed from the Yoswit App.
- Wi-Fi + Bluetooth coverage: Bluetooth mesh strengthens local coverage; Wi-Fi enables remote control; better wall penetration and whole-home reach.
- Third-party smart-home compatible: Works with mainstream ecosystems such as Google Home and other platforms for cross-platform control.
- OTA remote upgrade: New features and bug fixes pushed remotely, no manual intervention.
- No gateway / no rewiring / no complex setup in the Yoswit smart-switch philosophy.
- LED compatible: Single-wire (no-neutral) LED support from 3W and above.
Mechanical Specifications
Item | Value |
|---|---|
Operating Environment | Indoor |
Operating Temperature | -10°C ~ 40°C |
Operating Humidity | 0–95% RH, non-condensing |
Control Method | App / Manual |
Ingress Protection | IP20 |
Panel Size | 86 × 86 mm (86-type) |
Electrical Specifications
Item | Value |
|---|---|
Input Voltage | Not shown in extracted page — see datasheet |
Power Consumption | Not shown in extracted page — see datasheet |
Max Load | 20A high-power load (per marketing copy); exact wattage see datasheet |
Wireless Specifications
Item | Value |
|---|---|
Connectivity | Wi-Fi 2.4GHz + BLE 4.2 |
Bluetooth | Bluetooth 4.2 (BLE) |
Ecosystem | Yoswit App, Google Home / third-party platforms |
Range | Not explicitly listed; Wi-Fi remote + BLE local mesh |
App Compatibility
- iOS 13.0 or later
- Android 7.0 or later
- Yoswit App (iOS / Android APK)
- Bluetooth Smart Ready devices supported
Package / Documents
- Smart double-pole switch main unit
- Mounting screws
- User manual (EN / Simplified Chinese)
- Datasheet
- Leaflet: Smart Lighting Switch
- Product catalogue / Hong Kong product catalogue
