KX6

KX6 coaxial cable
DESCRIPTION
Used as a distribution cable for indoor CATV, CCTV system and as a connection cable for satellite system where lower attenuation required.
CABLE CONSTRUCTION
KX6
Conductor	Stranded bare copper	7*0,20 +/-0,005 mm
Insulation	Solid PE	3,70 +/-0,10 mm
Shield	Aluminum alloy braid 16 x 6 x 0,12mm	80%
Sheath	PVC	6,10+/-0,10 mm
Color	Green
Bending radius	≥ 8 x Diameter (mm) Installation
Storage temperature	-15℃ + 70℃

*ELECTRICAL SPECIFICATIONS*
Nominal Impedance	75+/-3	Ohm
Capacitance approx	67+/-3	pF/m
Velocity ratio	65.9	%

Attenuation at 20°C MHz			dB/100 m
10			5
50			8.1
100			13.0
200			18.5
400			22.5
800			34.5
950			37.5
1000			45.0

PACKING

100 m/box

305 m/wooden drum

305 m/plastic reel

500 m/wooden drum

All sizes and values without tolerances are reference values. We reserves the right to amend this specification without prior notice.
