Displayed here is a switching DC power supply with single phase and single output. It offers constant voltage and constant current operation and both the current and voltage can be adjusted from 0 to the rated value. This switching DC power supply has a LED digital display and has an intelligent temperature control fan to help cool the power supply quickly.

Features:

• Single phase, single output DC power supply.
• Constant voltage and constant current operation (C.C and C.V. automatic conversion)
• Both current and voltage can be adjusted from 0 to the rated value.
• 3 LED digital display.
• Intelligent temperature control fan to help cool the power supply quickly.
• Rectangular shape.
• With ventilation holes on the side.
• Knob switches for control.
• Model: LW-1510KDS/LW-1520KDS/LW-3005KDS/LW-3010KDS/ LW-6402KDS/ LW-6403KDS/ LW-6405KDS/ LW-1003KDS.


Specifications:

• Input voltage: single-phase 220V±10% 50Hz ±2Hz.
• Working conditions: -100C -400C relative humidity :< 90%.
• Storage conditions: -200C-800C relative humidity :< 80%.
• Output voltage: 0-15V/0-30V/0-64V/0-100V.
• Output current: 0-2A/0-3A/0-5A/0-10A/0-20A.
• Display accuracy: ±1%±1 digit.
• Voltage stabilization: ≤0.05%+1mV.
• Current stabilization: ≤0.1%+10mA.
• Load stabilization: CV≤0.1%+1mV,CC≤0.1%+10mA.
• Ripples and noises: CV≤10mV(rms),CC≤20mA(rms)


Applications:

• Charge batteries, PCB board manufacturing industry.
• LED products, motors and dc fans test.
• Electrofacing, electrolyzation, electronic components aging.
• Laboratory, electronic equipment , automatic test equipment.
• All other occasions needed to use DC power supply.
• Protection function: short-circuit protection, current limitation protection.
