32.768KHz 2012 SMD Crystal 32.768K SMD Xtal | 無源元件

CRYSTAL BRIGHT GROUP(HK)LIMITED

32.768KHz 2012 SMD Crystal 32.768K SMD Xtal

品牌:

JGHC晶光华

是否可訂造:

可以

型號編號:

H21

尺寸:

2.0x1.2x0.6mm

Nominal Frequency:

32.768KHz

Load Capacitance:

7pF/9pF/12.5pF

Frequency Difference:

10ppm/20ppm

Website:

www.jghcorp.com

描述

聯絡供應商

32.768KHZ Clock Crystal Resonator 2.0x1.2x0.6mm H21 Series

Features

✦2 pads surface mount package;

✦Applications in mobile phone, Notebook and DSC;

✦High reliable environmental performance;

✦RoHS Compliant / Pb Free;

Crystals specifications

ITEMS/TYPE	H21
Nominal Frequency	32.768KHz
Load Capacitance	7pF,9pF,12.5pF, or specify
Frequency Tolerance (at 25℃)	±20ppm, or specify
Operating Temperature Range	-40~+85℃, or specify
Parabolic Coefﬁcient (B)	(-0.036±0.006) 10^-6* / ℃²
Motional Capacitance(C1)	3.0fF typical
Shunt Capacitance (C0)	1.2pF typical
Drive Level	1.0μW Max.
Aging (at 25℃)	±5ppm/year Max.
Storage Temperature Range	-55~+125℃
