2022 New Model Stylish Electric Scooter
美元 $259.60 - 美元 $313.50
生產所需時間:
30 日
運送方式:
By sea, By air, By courier
型號編號:
LC 97927
Battery capacity (AH):
10.0AH/7.5AH
Rated voltage (V):
42V/54.6V
Charging input voltage (V):
42V/54.6V
Battery charge times:
500~800 times
Rated power (W):
64W/84W
Rated input voltage (V):
90V~260V 50/60Hz 2A
Rated current (A):
1.5A
描述
聯絡供應商
描述
| Performance | project | Technical Parameters | |||||||
| Body material & size | Body color | Red Black | |||||||
| Body material | Steel, aluminum alloy | ||||||||
| Folding size (mm) | 1130*515*520 | ||||||||
| Expanded size (mm) | 1130*515*1190 | ||||||||
| Pedal distance from the ground (mm) | 70mm | ||||||||
| Car body mass | Applicable height (cm) | 155cm~200cm | |||||||
| Body weight (kg) | 18.3KG | ||||||||
| Car body ultimate load (kg) | 120kg | ||||||||
| Vehicle parameters | Top speed (km/h) | Standard 25KM/H, optional 20KM/H or 30KM/H | |||||||
| Cruising mileage (km) | 38KM | ||||||||
| Applicable terrain | Hardened cement pavement, flat asphalt pavement, ramps less than 15°, and no more than 2cm steps. | ||||||||
| Operating temperature | 0℃~45℃ | ||||||||
| waterproof level | IP54 | ||||||||
| Brake system | Front drum brake rear disc brake | ||||||||
| Gross weight (KG) | |||||||||
| Motor (wheel) parameters | Rated power (W) | 350W、450W | |||||||
| Rated voltage (V) | 36V/48V | ||||||||
| Rated current (A) | 16A | ||||||||
| Rated torque (N.m) | 14N.m | ||||||||
| No-load current | ≤0.9A | ||||||||
| No-load speed | 520±10rpm (After configuring with the controller) | ||||||||
| Rear driven wheel size | 10 inches | ||||||||
| Front motor wheel size | 10 inches | ||||||||
| Controller + instrument | Rated current (A) | 16A | |||||||
| Rated voltage (V) | 42V/54.6V | ||||||||
| Speed gear | 3 gears: 1st gear energy-saving mode, speed 15KM/H. 2-speed comfort mode, speed 20KM/H. 3 gear sports mode, speed above 25KM/H. | ||||||||
| test temperature | Range: -15℃~75℃ normal operation | ||||||||
| Craft | Aluminum-free, and the surface of electronic components is treated with three anti-oxidation paint | ||||||||
| Battery pack parameters | Cell specifications | 18650 batteries (10S4P 40 batteries) The battery pack is removable 18650 batteries (13S3P 39 batteries) The battery pack is removable | |||||||
| Battery capacity (AH) | 10.0AH/7.5AH | ||||||||
| Rated voltage (V) | 42V/54.6V | ||||||||
| Charging input voltage (V) | 42V/54.6V | ||||||||
| Smart BMS | Balance/overcharge/over discharge/overcurrent short circuit protection | ||||||||
| Battery charge times | 500~800 times | ||||||||
| Charger parameters | Rated power (W) | 64W/84W | |||||||
| Rated input voltage (V) | 90V~260V 50/60Hz 2A | ||||||||
| Rated current (A) | 1.5A | ||||||||
| Charging time (H) | ~5H | ||||||||
| Rated output voltage (V) | 42V/54.6V | ||||||||
| Headlight | Operating Voltage | 5V | |||||||
| Working current | 200mA | ||||||||
| taillight | Operating Voltage | 5V | |||||||
| Working current | 20mA | ||||||||
2022 New Model Stylish Electric Scooter
