30mw Solar Tracking System With Hign Efficiency&Competitive Price
品牌名稱:
suoyang
港口:
shenzhen
付款方式:
T/T,L/C,W.U.
最低訂購數量:
10pcs
類型:
聚焦式太陽能光伏電產品, 太陽能光伏電系統專用變流器, 太陽能光伏電組件及器材, 太陽能光伏單元件, 太陽能光伏電膜組及膜塊, 太陽能光伏系統及軟件, 太陽能光伏聯產系統及軟件, 農村光伏發電系統, 太陽能檢測及控制系統, 太陽能光伏電系統技術
是否有包裝:
有
是否可訂造:
是
描述
聯絡供應商
描述
Specifications
Tracking accuracy 0.1 around
Quality guarantee 25Y 2Y
All structure components are hot-dip galvanized, 25years service life.
5KW
1. Adopting20 Pcs 250W Pv modules.
2. Module dimension:1650*992*40 Weight 17 kg.
3. Installing 20pcs modules per set and module layout as the right drawing.
4. Plane frame design.
5.We can provide the installation video.
B. Technical Parameters
Product Item Reference Data Item Reference Data
dual-axis tracker Control Method Time Control Operation under Max. wind speed 35m/s
Tracking accuracy (°) ≤ 0.2 Wind Protection 17 m/s
Motor voltage AC: 220V Material Zinc-galvanized steel
Driving Power (W) 90×2 Mechanical Lifetime (Y) >25
Daily power consumption (kwh/day) 0.5 Motor Lifetime (Y) >3
Azimuth angle tracking range (Deg) -120~120 Operating Temp (°C) -40°C~85°C
Elevation angle tracking range (Deg) 30~90 Certified CE
10KW
1. Adopting40 Pcs 250W Pv modules.
2. Module dimension:1650*992*40 Weight 17 kg.
3. Installing 40pcs modules per set and module layout as the right drawing.
4. Plane frame design.
We can provide the installation video.
B. Technical Parameters
Product Item Reference Data Item Reference Data
dual-axis tracker Control Method Time Control Operation under Max. wind speed 35m/s
Tracking accuracy (°) ≤ 0.2 Wind Protection 17 m/s
Motor voltage AC:380V Material Zinc-galvanized steel
Driving Power (W) 90×2 Mechanical Lifetime (Y) >25
Daily power consumption (kwh/day) 0.5 Motor Lifetime (Y) >3
Azimuth angle tracking range (Deg) -120~120 Operating Temp (°C) -40°C~85°C
Elevation angle tracking range (Deg) 30~90 Certified CE
Tracking accuracy 0.1 around
Quality guarantee 25Y 2Y
All structure components are hot-dip galvanized, 25years service life.
5KW
1. Adopting20 Pcs 250W Pv modules.
2. Module dimension:1650*992*40 Weight 17 kg.
3. Installing 20pcs modules per set and module layout as the right drawing.
4. Plane frame design.
5.We can provide the installation video.
B. Technical Parameters
Product Item Reference Data Item Reference Data
dual-axis tracker Control Method Time Control Operation under Max. wind speed 35m/s
Tracking accuracy (°) ≤ 0.2 Wind Protection 17 m/s
Motor voltage AC: 220V Material Zinc-galvanized steel
Driving Power (W) 90×2 Mechanical Lifetime (Y) >25
Daily power consumption (kwh/day) 0.5 Motor Lifetime (Y) >3
Azimuth angle tracking range (Deg) -120~120 Operating Temp (°C) -40°C~85°C
Elevation angle tracking range (Deg) 30~90 Certified CE
10KW
1. Adopting40 Pcs 250W Pv modules.
2. Module dimension:1650*992*40 Weight 17 kg.
3. Installing 40pcs modules per set and module layout as the right drawing.
4. Plane frame design.
We can provide the installation video.
B. Technical Parameters
Product Item Reference Data Item Reference Data
dual-axis tracker Control Method Time Control Operation under Max. wind speed 35m/s
Tracking accuracy (°) ≤ 0.2 Wind Protection 17 m/s
Motor voltage AC:380V Material Zinc-galvanized steel
Driving Power (W) 90×2 Mechanical Lifetime (Y) >25
Daily power consumption (kwh/day) 0.5 Motor Lifetime (Y) >3
Azimuth angle tracking range (Deg) -120~120 Operating Temp (°C) -40°C~85°C
Elevation angle tracking range (Deg) 30~90 Certified CE
