4000 Digits Digital Clamp Multimeter
生產所需時間:
5 - 15 日
产品型号:
DM6016B
品牌名称:
VICHY
顏色:
Orange, Grey
尺寸:
185 x 93 x 35mm
港口:
Shenzhen
最低訂購數量:
40 piece(s)
是否可訂造:
是
测量范围:
DCV/ACV/ACA/Resistance/Capacitance/Frequency/Temperature/Diode Test
工作溫度:
23+-5C
顯示方式:
數字
描述
聯絡供應商
描述
- Clamp open 35 mm
- Portable design, easy to operate.
- Full function protection, anti high voltage circuit design
- CE stander design, improve the safety of the test.
- Relative value, data hold.
- OEM available.
- Color: body: dark grey; clamp head: orange
- Technical data:
- DCV 400mV/4V/40V/400V/600V ±(1.0%+3)
- ACV 4V/40V/400V/600V ±(1.5%+5)
- ACA 40A/400A/1000A ±(2.0%+5)
- Resistance 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ ±(1.0%+3)
- Capacitance 40nF/400nF/4uF/40uF/200uF ±(3.0%+5)
- Frequency 100Hz/1kHz/10kHz/100kHz/1MHz/10MHz ±(0.5%+3)
- Temperature (-40~ 1000) ℃ ±(0.8%+4)
- Special functions:
- Diode test
- Continuity alarming: Less than 50Ω±10Ω
- Low battery indication: Approx less than2.4 V
- Data hold: Data hold/Max. hold
- Auto power off: About 15minutes
- Function protect: Full function protection
- Input impedance: 10MΩ
- Sampling rate: 3 times/s
- AC frequency response:Amperemter50Hz/Voltage(50-400)Hz
- Operation way: Manual or auto range
- Max. display:4000
- Clamp open:35mm
- Battery:3V (2*1.5V) AAA
- General characteristics:
- Color: Orange and Grey
- Weight: About 200g (include 2*1.5v battery.)
- Standard accessory: Test leads, battery, manual,TPO1 temperature probe
- Packing: Gift box
- Carton size:50.5*26.5*47CM
- Standard packing per carton:40PCS
- Standard G.W. per carton:18KG
