Product Description:

• Quad Core HD TV Box support DVB S2
• Android base TV system
• IPTV, VOD, KODI, Youtube, Redtube
• H.264 1080p Video encoding
• H.264/H.265 decoding up to 4K×2K@30fps

Basic parameters:

• System SoC: Allwinner H3
• CPU: ARM Quad Cortex-A7 up to 1.2GHz
• GPU: Mali-400MP2
• DRAM: DDR3 1GB (2GB/512MB Optional)
• Flash: EMMC 8GB( Nand/EMMC 4GB,8GB,16GB,32GB Optional)
• OS: Android N
• Network RJ45 Interface 10M/100M adaptive
• Build in Wi-Fi 2.4GHz 802.11 b/g/n(2.4GHz, 5GHz, BT Optional )
• Tuner Tuner+DEMO: M88RS600B
• Frequency Range: 950~2150MHZ
• Input Level: -65~-25dBm
• Input impedance: 75Ω
