Product Description:

• Quad core 64 bit 6K HDR Android Hybrid Box support ISDBT
• Android base TV system
• H.264 1080p 60fps Video encoding
• H.264/H.265 10bit HDR decoding up to 4K@60fps/6K30fps
• HDMI 2.0 max to 4K60 output, USB 3.0

Basic parameters:

• System SoC: Allwinner H6
• CPU: Quad-core ARM Cortex TM -A53 up to 1.8G Hz
• GPU: Mali-T720MP2
• DRAM: DDR3 1GB (2GB Optional)
• Flash: EMMC 8GB( EMMC 16GB,32GB Optional)
• OS: Android N
• Network RJ45 Interface 10M/100M adaptive (1G Optional)
• Build in Wi-Fi 2.4GHz 802.11 b/g/n(2.4GHz, 5GHz, BT Optional )
• Support most external 3G/4G USB dongle(Optional)
• Tuner Tuner+DEMO: MXL608+AVL6812
• Frequency Range: (VHF)174~230MHz, (UHF)474~858MHz
• Input Level: -85dBm~-20dBm
• Input impedance: 75Ω
