Characters:
★ New design, the thickness is 45mm, back-lighting.
★ Optimum light uniformity and high color homogeneity
★ LED Source: high brigntness SMD 2835
★ Luminous efficiency: 100lm/W
★ Beam angle: 120dg
★ Lifespan: 50000hrs
★ Installation: Recessed, Suspended Mounted.
★ Standards: CE, RoHS approved.
★ Heat dissipation: Aluminum PCB ensure excellent heat dissipation.
★ Optional dimming: Infrared,0-10v,DALI.

Application:
1. Commercial lighting: high-class stores, shopping malls, hotels, restaurants, airport.
2. Office lighting: Conference, Factories, offices.
3. Institution Buildings: schools, hospitals, pharmacy.
• Item No. AT-DPL-S0606S6-032
Electrical Parameters:
• Power 32W
• Input Voltage AC100-277V (50/60Hz)
• LED style 324pcs SMD 2835
• output current 600mA
• output voltage 54V
• Power Factor ﹥0.9
Optical Parameters:
• Luminous output 3000lm@3000K,3200lm@4000K, 3200lm@6000K
• Color Temp (CCT) 3000K/4000K/6000K
• Color Rendering ﹥80
• Beam Angle 120dg
• Uniformity ﹥90%
Physical Parameter:
• Material ABS+Iron+PS
• Lighting method Back-lit
• Power supply External driver (included)
• Operation Temperature -20°C ~ +45°C
• Storage Temperature -25°C ~ +55°C
• Protect Level IP20
• Certificate CE, RoHS
