Feature:

• 4W RF power
• 40 AM/FM channels
• Channel 9 and channel 19 switch
• Mode AM/FM switch
• With adjustable ASQ
• RSSI indication (4-digit LED indication)
• 2 Digit channel indication
• RF gain control
• Volume with power ON/OFF control
• TX/RX LED indication
• Up/Down microphone
• Front microphone plug
• Jack for external speaker
• Manual Squelch
• ANT Connector
• FREQ. expanding (A,B,C,D,E,F,POLAND and NZ band)

Technical Indicators:

• Channels : 40 AM/FM
• Frequency range : 26.965 – 27.405MHz
• Frequency control : P.L.L.
• Frequency Tolerance : ±0.005%
• Operating temperature : -20°/+55°C
• DC input voltage : 13.8Vdc ±15%
• Size : 115 (L) x 38 (A) x 150 (P) mm
• Weight : 0.8 kg

Receiver:

• System : CPU controlled Double conversion super
• IF : 1° 10.7 MHz / 2° 450 KHz
• Sensitivity (FM) :  -120dBm for 12dB SINAD
• Sensitivity (AM) :  -107dBm for 12dB SINAD
• Audio output : @10% THD 2.5W at 8 ohm
• Audio distortion : <8% at 1 KHz
• Image rejection : 65dB
• Adjacent channel : 85dB
• Signal ise ratio : 45dB
• Current drain : 220mA (stand-by)

Transmitter:

• System : CPU controlled P.L.L. synthesizer
• Maximum RF power : 4W at 13.2Vdc
• Modulation (AM)  :  85% to 90%
• Modulation (FM) :   2KHz ±0.2 KHz
• ANT impedance : 50 ohm unbalanced
• Current drain : 1500mA (at no modulation)
