Product Features

• Built-in isolated adjustable power color temperature LED driver
• Support DALI-2, Push Dimmingcolor temperature LED driver
• NFC control adjusts the current
• Current adjustment via NFC
• Output current 350…850 mA
• Max. output power 30 W
• Flicker free LED driver
• For luminaries of protection class l, ll

• 5-year warranty

Description

• Constant current driver with wide operating windows
• Supports DALI-2, push DIM and push CCT
• Supports NFC readers for precise setting and control of multiple functions
• Supports two independent DT6 or one DT8 output
• Smooth colour temperature setting and dimming with dimming range 1-100% (amplitude dimming)
• Equipped with i-Data (30W, 44W, 60W): enabling data management according to DALI parts 251, 252 and 253
• The DC emergency mode adjusts the current to 15% by default (adjustable), applies to 30 W, 44 W, 60 W versions
• Loop through connection comply with 2.5 mm² engineering cable entry specifications
• Standby power consumption ≤ 0.3 W (30-60 W), < 0.5 W (20 W), meets ErP energy efficiency certification
• Packing unit programming: configure a large number of drivers in parallel via NFC
