• Anti-theft digital door lock basic system.
• Power supply DC6V 4 1.5V AA (no.5) batteries.
• Alarmed low voltage 4.0V.
• Lowest working voltage 3.3V.
• Outdoor emergency power supply DC9V.
• Door open-ways password verification, emergency mechanical key, fingerprint (optional module), IC card (optional module), wireless remote control (optional module), remote call (optional module).
• LCD display 2.5 inch color TFT LCD optional.
• Illegal open alarming support.
• No closed notice support.
• Close door automatically automatically close door 5 second after open.
• Voice help voice help on every action.
• Motor Japan micro DC motor with high reliability.
• False access system will hold for 30minutes with 5 continues wrong access.
• Mixed password can open door if only entering right password among mixed no more than 23 alphabet.
• Lock body standard anti-theft mechanical lock body with high reliability.
• IC card mifare one.
• Handle stainless steel foundry.
• Sleep current <15uA.
• Peak working current <200mA.
• Size front housing: 280 x 74 x 33mm.
• Back housing 280 x 74 x 32mm.
• Lock body surface: 240 x 24mm.
• Door thickness: 40-110mm.
• Working temperature: -10 to 50.
• SDL8000-AFB-GB golden black colored.
• SDL8000-AFB-SB silver black colored.

SDL8000-MF0-1:

• Optical fingerprint module.
• Template files 120.
• False accept rate (FAR): <0.001%.
• False reject rate (FRR): <0.1%.
• Search time <1.0s.

SDL8000-MFS-1:

• Scratch dermal fingerprint module.
• Template files 162.
• False accept rate (FAR): <0.008%.
• False reject rate (FRR): <0.005%.
• Search time <1.0s.

SDL8000-MFC-1:

• Capacitive fingerprint module.
• Template files 120.
• False accept rate (FAR): <0.008%.
• False reject rate (FRR): <0.005%.
• Search time <1.0s.

SDL8000-MPE-1:

• Video peep-hole eye module LCD 2.5 inch 4:3.
• LCD resolution 320 x 240.
• Camera CMOS.
• Camera pixels 300K pixels.
• Infrared backlight yes.

SDL8000-MRC-1:

• Wireless remote controller frequency 433MHz.
• Working distance 10m with no obstacle.

SDL8000-MTM-1:

• Gateway between digital lock and mobile phone RF frequency 433MHz.
• Working distance between digital lock and gateway 10m.
• Mobile phone system GSM.
