Introduction:

Real time PCR is used for sensitive, specific detection and quantification of nucleic acid targets. We have developed powerful assay design algorithms, optimized qPCR regent, intuitive data analysis software. and flexible instrumentation to help harness the power of qPCR across a rich and diverse set of applications. Explore our robust solutions for your qPCR based research.

Application:

It can be widely used for infectious disease research, Food pathogen detection, Waterborne pathogen detection, Pharmaceutical analytics, Stem cell research, Pharmacogenomics, Oncology and genetic disease research, Plant sciences and agricultural biotechnology.

Working Priciple:

The temperature step change is controlled by the semiconductor peltier to realize PCR amplification. Use high sensitivity MPPC unit to detect fluorescence; Program control channel switching, non contact excitation/detection on the top structure,coordinated with motor control x and y axis movement to achieve 96 hole scanning. Finally, accurate analysis is carried out through powerful software.

Features:

* Excellent temperature control performance of the instrument, the maximum temperature rise and fall ≥5.0°C/s.

* No edge effect, no optical path correction, top excitation/detection, non-contact measurement.

* Fluorescence detection adopts MPPC sensor with high sensitivity.

* Long life LED light source, stable emission wavelength, maintenance free.

* 4 channel fluorescence detection, no cross interference between channels.

* User friendly and fully functional software, flexible program setting, comprehensive analysis and reporting functions, all the parameters can be stored.
