Features
1. Advanced thermal conductive plastic radiator,good heat dissipation performance, long lifespan.
2. You can choose dimmable or non-dimmable.
3. Internal driver and fit for most of dimmers including leading-edge dimmer.
4. High cost effective
5. Wide 100 degree beam angle.
6. IC-4 rated, can be safely covered and abutted to building insulation.
7. High efficiency SMD LED Array, can up to 110lm/w.
8. Single CCT and Tri-colour all can be choosed here.
9. Approved with SAA, C-tick, CE, RoHs certification
10. High light transmittance PC diffuser is used here, lumen efficiency can be up to 110lm/w.
11. CCT switcheable: the switcher is on the top of the light, customer can easily switch to 3000K/4000K/5000K and reduce the stock.
12. Optional to use metal fascia on the light. Chrome, nickel, zinc, silver, black , copper and golden fascias all can be done.
Models
Model | Power | Cut-out | Diameter | Height |
SM-DL01-10-06-F | 10W | 150mm | 190mm | 70mm |
SM-DL01-16-06-F | 16W | 150mm | 190mm | 70mm |
SM-DL01-18-06-F | 18W | 150mm | 190mm | 70mm |
SM-DL01-20-06-F | 20W | 150mm | 190mm | 70mm |
SM-DL01-10-08-F | 10W | 180mm | 225mm | 80mm |
SM-DL01-18-08-F | 18W | 180mm | 225mm | 80mm |
SM-DL01-20-08-F | 20W | 180mm | 225mm | 80mm |
SM-DL01-25-08-F | 25W | 180mm | 225mm | 80mm |
