Product Description

MAS-AF310 is the flagship model of Sapiens Mini Air Station (MAS) series products for high-performance and long-term outdoor air quality monitoring with integrated autonomous data quality control capabilities. Enabled by an intelligent heated sampling inlet, the product can measure PM1 /PM2.5 /PM10 with more than 50 size channels from 0.3 μm to 10 μm with less interference from changing environmental conditions. Autozero function is enabled to track the long-term drift issues for PM measurements. Data transmission to designated Sapiens cloud server or user designated server through API and direct TCP links are optional. The intended applications are complementary air quality monitoring with high data performance target needs and near reference data quality requirement for the government agency, communities, air quality researchers and industrial sectors

Product Features

• Omnidirectional inlet design for gas and PM measurements;
• Stevenson screen protected high performance climatic measurement for ambient temperature and humidity;
• IP65 grade waterproof design for all weather condition outdoor monitoring;
• Highly integrated for simultaneous measurement of PM1 , PM2.5 , PM10 with more than 50 size channels from 0.3 μm to 10 μm;
• Sheath flow is enabled for PM counter model for high concentration measurements and long-term performance;
• Aerodynamically validated PM inlet cyclone for near reference PM1 , or PM2.5 or PM10 measurements;
• Correction of laser drift and humidity impact though auto zero function and intelligent heating for PM measurement;
• Data transmission via 4G network for continuous and real time monitoring through cloud platforms;
• Versatile installation options of tripod, wall mount and crossarm;
• External smart battery packs are optional for extended outdoor powerless operation for up to 5 days;
• Solar power panels are optional for extended operations in remote outdoor environments.

Applications

• Smart city sensor network
• Urban air pollution monitoring
• Roadside air quality monitoring
• Industrial fence line monitoring
• Emergency air quality monitoring

Please contact us for price details

sales@sapiens-envtech.com
