PC Material 3x11 Lens Array 60 degrees with IP66 Protection Can Pass IK08 Test

• Model: ALHB321D66LED60GIP
• Diameter: 321.0mm,
• Height: 79.0mm
• Angle: 60°
• Material: PC-1250Z
• Transmittance: >90%
• LED Applications: 3030''5630''5050
• Lighting applications: High Bay lighting, Linear Lighting
• ASAHI OPTICS released a new lens 3X11 array with IP66 protection  the lens is made of PC material, which can pass IK08 test
• The 3X11 lens array is designed for Mid Power LEDs which is compatible with “3030” and “5630”LEDs.
• Especially for each optical surface, it is not only for single LED but also for double LEDs to get much high lumens.
• For more details, please check our website.

Our Services

• Innovative in LED Optical Engineering and Manufacturing Services
• Quick response (Quick-turn of new development)
• Strong R&D Team (Excellent engineering team with 10 years of experience), committed to bringing our customers the best LED optical designs.
• Production (Advanced equipment, Tooling dimensional accuracy is within 0.01mm, Optical finishing accuracy is within 0.001mm, Tolling lifetime can reach 500,000 shots.)
• Marketing (Wide range of products)
• One-stop service for private mold optics design, and mass production.
• Services (Thorough and satisfactory before & after-sales service)
