TSX 1612 SMD Crystal 26MHz-76.8MHz Xtal | 無源元件

CRYSTAL BRIGHT GROUP(HK)LIMITED

TSX 1612 SMD Crystal 26MHz-76.8MHz Xtal

品牌:

JGHC晶光华

是否可訂造:

可以

型號編號:

T16

尺寸:

1.6x1.2x0.65mm

Nominal Frequency:

26-76.8MHz

Load Capacitance:

20pF or specif

Frequency Difference:

±20ppm or specif

Email:

alan@jghcrystal.com

Website:

www.jghcorp.com

描述

聯絡供應商

SMD 1612 Seam Temperature Sensing Crystal 1.6x1.2x0.65mm T16 Series

Our Temperature Sensing TSX Crystal provide better frequency stability and higher reliability for diverse mobile

communication and harsh automotive applications.

Features

High precision and high frequency stability；

Excellent thermal coupling between thermistor and crystal；

Application in mobile communications

RoHS Compliant / Pb Free

Crystals specifications

ITEMS/TYPE	T16
Frequency Range	26~76.8MHz
Load Capacitance	12pF, or specify
Frequency Tolerance (at 25 ℃)	±10 ppm, or specify
Frequency Stability Over Operating Temperature Range	±10 ppm, or specify
Operating Temperature Range	-40~+85℃, or specify
Shunt Capacitance (C0)	3pF Max.
Drive Level	1~200μW (50μW typical )
Aging (at 25 ℃)	± 1 ppm / year Max.
Storage Temperature Range	-40~ + 105 ℃
Thermistor Resistance (25℃)	100kΩ , or specify
Thermistor B-constant (25~50℃)	4250, or specify
