We offer one-stop PCB assembly services. Our services include 1-to-12-layer PCB fabrication, PCB design, PCB layout, PCB manufacturing, PCB assembly, component sourcing, PCBA function test and design solution. Our profiling punching includes routing, V-cut and beveling.

• Layer: 1-12 layers.
• Material: FR-1, FR-2, FR-4, CEM-1, CEM-3, high TG, FR4 halogen free.
• Board thickness: 0.2-3.5mm.
• Max panel size: 630 x 520mm.
• Min. drilled hole size: 0.5mm.
• Min. line width: 0.075mm (3mil).
• Min. line spacing: 0.075mm (3mil).
• Surface finish/treatment: HASL/HASL lead free, chemical tin, chemical gold, immersion gold, immersion silver/gold, OSP, gold plating.
• Copper thickness: 0.5oz min, 5oz max.
• Solder mask color: green, black, white, red, blue and yellow.
• Inner packing: vacuum packing and plastic bag.
• Outer packing: standard carton packing.
• Hole tolerance: PTH: ±0.076, NTPH: ±0.05.
• Certificate: UL, ISO9001, ISO14001, ISO/TS16949 and RoHS.
• Profiling punching: routing, V-cut and beveling.
• OEM services only.
