1. Mainstream 384*288, UFPA (FPA, uncooled microbolometer) Infrared detector
2. Diverse Optional Lens Configuration
3. IP66 Encapsulation Grade
4. Digital enhancement technology，Automatic tracking alarm function
5. Fully compatible with existing network surveillance system (JK362-PoE)
6. Powerful Operation software system

Infrared
Detector type   FPA,uncooled microbolometer
Resolution   384×288
Thermal sensitivity   0.05℃@30℃
Spectral range   8～14um
Focal length/FOV   9mm:60°x44°（Standard）/13mm:42°x31°/19mm:29°x22°/35mm:14°x10°/50mm: 11°x8°/100mm: 5.5°x4.1°
Focusing   Focus free athermal lens
Frame rate   25Hz/30Hz
Format  PAL/NTSC Composite Video,H.264 Network digital Video
Processing   Automatic Gain Control(AGC),Digital Detail Enhancement(DDE)
Interfaces
AV out  Yes
RJ45 Ethernet  Yes
Alarm Input   Yes
Alarm Output   Yes
WiFi  Optional
USB Storage  Optional
Power
Requirements   12V DC or PoE
 Consumption   ≤35W (With Temperature controlling)
Start-up time   ≤60 s
Environment Specification
Operating temperature range   -35℃～+65℃
Storage temperature range    -40℃～+70℃
Humidity    ≤95％ non-condensing
Encapsulation    IP 67
Shock resistance    25G
Vibration resistance    2G
Automatic heater   Deicing from the windows
Physical characteristic
Weight   3 kg
Size    362mm×140mm×145mm
System Features
System state self-check  Yes
DDE  Yes
Network connection  Optional
Two-way voice  Optional
Video motion detection (VMD)  Optional
Sensitive area shelter   Optional
DHCP  Optional
OSD   Optional
PTZ control  Optional
PTZ preset positions inspection  Optional
PTZ auto-tracking  Optional
Boundary alarm   Optional
Solar power supply  Optional
video recording   Yes
image recording   Yes
Text annotation   Yes
